The roller is mainly used to compact asphalt, sand and gravel. It is also used to compact and level the lawn on the school runway. This is the latest model of light roller in the country.
1. Tandem rollers, also known as double-drum rollers, are equipped with a mechanical parking brake that keeps the machine stationary when parked.
2. Push-button control ensures safe reverse travel.
3. The operating handle can be folded down or kept at a certain angle to the ground, which is comfortable to operate and easy to transport.
4. Built-in oil cooler keeps the hydraulic system
5. Vibration reduction control to reduce operator arm vibration.
6. Minimum side clearance allows for as close as possible to curbs, walls and other obstacles.
7. Two smooth steel wheels work together to compact the ground evenly and keep it flat. The steel wheel edges are beveled to eliminate marks on the compacted surface.
8. Front-mounted diesel engine for easy operation by maintenance personnel.
9. A 35-liter corrosion-resistant water tank is equipped at the rear end of the roller. It reduces noise and keeps dust to a minimum.
10. An easily accessible on/off switch controls the start or stop of the vibrating movement.
Operating weight：430kg
Total length (armrests laid flat)：1900mm
Total width：860mm
Total height (armrests erected)：1520mm
Vibration form：One-button vibration-electromagnetic clutch
Engine optional (National II/National IV/EPA/Euro V)：Changfa 178/Honda GX270
Other engines can be consulted separately
Efficient single-person operation: The handle integrates the throttle, vibration switch and emergency stop button, so the operator can control it with one hand while walking and following, reducing physical exertion.
Real-time adjustment of compaction path: The operator can observe the contact status between the steel wheel and the material at close range, and adjust the walking route or vibration mode in time to avoid pressure leakage or material displacement.
Emergency brake protection: The design of stopping when releasing the hand (centrifugal clutch or brake system) quickly cuts off the power in an emergency to reduce the risk of accidents.
Narrow space operation: The width of the machine body is usually only 60cm, which can easily enter narrow areas (such as pipeline trenches, the inside of curbstones, and basement passages), filling the compaction blind spots that large equipment cannot cover.
Quick transition: The weight of the whole machine is moderate, and the handle can be removed or folded to be transported by small trucks, pickup trucks, or even manpower, which is suitable for contractors who frequently transfer to multiple construction sites.
Terrain adaptability: The steel wheel has a large diameter and can cross small obstacles (such as stones and gaps) and adapt to slightly uneven ground.
A: Color
B : Different engines (Changchai,Loncin, B&S, Honda, Yamaha,).
C: Labels customization.
D: Logo customization.
E: Package customization.
F: Manual books customization.
G: Structure components customization.
A:Solid carton,steel frame with carton cover or wooden case
A: Usually the MOQ is 1set, but it will be adjusted accordingly if customers need OEM or ODM customization.
A: Sample will take 10days,mass production will need 25days.
